JG-KYG 1800 Type Flexo Corrugated Carton Box Printing Die Cutting Slotting Machine
Edge feeder device
feed roller
A, send the paper roll is inserted using a single channel trench roller, wear rubber buffer selection, dynamic balance correction, to ensure smooth feeding and accurate.
B, lower feed roller embossing roll steel, hard chrome plating, wear balancing correction.
C, use upper and lower feed rollers gap Oldham type trimming device wrench adjustment dial display, easy adjustment, and self-locking.
● Automatically reset to zero means
A, the machine zero; press zero switch, convenient for a single operation, shorten the time for a single, reduce cardboard waste.
● Phase fixing system
A, pneumatic brakes.
B, the clutch unit, a transmission gear meshing point of the original constant.
Printing part
Rubber roller
A,Use high quality seamless steel ,dynamic balance
B,Steel face with high quality and wear-resisting rubber roller,long using lifetime
C,High grinding on face,adpot high precision and large area printing for branch
D,Trimming device,ensure uniform inking
● ink supply system
A,Pneumatic diaphragm pump,operation easy, convient maintai,supply ink reliable
B,Autoamtic cleaning ,automatic ink
phase adjust device
Phase adjusting adpot planet type gear confirguration,feature:big touch area,low noice
Electric adjust printing plante 360 degree (can adjust both run and stop)
C,Printing phase,encoder digital control
● fixes phase system
A,Pneumatic brakes device
B,Cluth,transmission gear the original mesh point remains the same
Paramater:
| Name of parameter | KSJ-900 | KSJ-1200 | KSJ-1400 |
| Color Group | Everything can be quipped according to users’ needs |
| Printing Paper | A,B,C,A/B,B/C and A/B/C Corrugated Cardboard(Maximum gap 11mm) |
| Production Speed | 180 Pieces/min | 170 Pieces/min | 160 Pieces/min |
| Economic Speed | 170 Pieces/min | 160 Pieces/min | 150 Pieces/min |
| Max.Paper Sizes | 900x1800/2000 2200/2400/2600mm | 1200x1800/2000 2200/2400/2600mm | 1400x1800/2000 2200/2400/2600mm |
| Min.Paper Sizes Positive knife Negative knife | 300x640mm 300x720mm | 350x720mm 350x740mm | 400x720mm 400x740mm |
| Max.Printing Sizes | 900x1600/1800 2000/2200/2400mm | 1200x1600/1800 2000/2200/2400mm | 1400x1600/1800 2000/2200/2400mm |
| Max.Die-cutting Size | 900x1700/1900 2100/2300/2500mm | 1200x1700/1900 2100/2300/2500mm | 1400x1700/1900 2100/2300/2500mm |
| Standard Printing Plate Thickness | 7.2mm |
| Slot Width x Max.depth | 7mmx220mm 7mmx300mm 7mmx350mm (Number of blade and slot depth may be added) |
| Min.Slot Space Positive knife Negative knife | 150*150*150*150mm 250*90*250*90mm | 170*170*170*170mm 260*90*260*90mm | 170*170*170*170mm 260*90*260*90mm |
| Printing Roller Dia | 300mm | 408mm | 480mm |
